Shelly Pro RGBWW PM

Physical

Size (HxWxD):

94x19x69 ±0.5 mm / 3.70x0.75x2.71 ±0.02 in

Weight:

61 g / 2.15 oz

Screw terminals max torque:

0.4 Nm / 3.54 lbin

Conductor cross section:

0.5 to 2.5 mm² / 20 to 14 AWG (green connector)
0.5 to 1.5 mm² / 20 to 16 AWG (blue connectors)
(solid, stranded, and bootlace ferrules)

Conductor stripped length:

6 to 7 mm / 0.24 to 0.28 in (green connector)
5 to 6 mm / 0.20 to 0.24 in (blue connectors)

Mounting:

DIN rail

Shell material:

Plastic

Shell color:

Yellow

Environmental

Ambient working temperature:

-20 °C to 40 °C / -5 °F to 105 °F

Humidity:

30 % to 70 % RH

Max. altitude:

2000 m / 6562 ft

Electrical

Power supply:

12-24 VDC

Power consumption:

< 1.5 W

External protection:

16 A, tripping characteristic B or C,
6 kA interrupting rating,
Energy limiting class 3

Output circuits ratings

Max. switching voltage:

24 VDC

Max. switching current:

16 A

Max. control current:

16 A (total), 6 A (per channel)

CCT range

2700K - 6500K (<- default, configurable to any range in between 1000K and 10000K)

Sensors, meters

Voltmeter (DC)

12 V - 24 V, ± 10 %

Voltmeter accuracy:

+/-5% (12V-24V DC)

Ammeter (DC)

0 mA - 5 A, ± 10 %

Ammeter accuracy:

+/-5%

Power and energy meters:

Active and apparent power

Active and apparent energy

Power factor

Fundamental active and fundamental reactive energy

Measurement data storage:

No

Internal-temperature sensor:

Yes

Radio

Wi-Fi

Protocol:

802.11 b/g/n

RF band:

2401 - 2495 МHz

Max. RF power:

< 20 dBm

Range:

Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors
(Depends on local conditions)

Bluetooth

Protocol:

4.2

RF band:

2400 - 2483.5 MHz

Max. RF power:

< 4 dBm

Range:

Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors
(Depends on local conditions)

Microcontroller unit

CPU:

ESP32-D0WDQ6

Clock frequency:

40 Mhz

Flash:

8 MB

Firmware capabilities

Schedules:

20

Webhooks (URL actions):

20 with 5 URLs per hook

Scripting:

Yes

MQTT:

Yes

Encryption:

Yes

Advanced schedules

Yes

KVS (Key-Value Store):

Yes
